Onkyo TX-NR616 WRAT Network AV Receiver Surround Multi Zone 7 HDMI

Expect outstanding all-round performance from the Onkyo TX-NR616 home theater receiver. Its THX® Select2 Plus™ badge of certification means it can reproduce riveting, accurate movie sound that'll have you glued to your TV screen. You also get the latest surround sound options, including Dolby® TrueHD and DTS-HD™ Master Audio, two high-resolution formats found on many Blu-ray movies. The 'NR616 uses Onkyo's WRAT (Wide Range Amplifier Technology) and a high-current power supply to deliver dynamic, punchy sound that stays clean even at higher volume levels.

You can also expect amazing video quality with the 'NR616's Marvell Qdeo™ processor. This circuitry is designed to show you all your favorites, new or old, at their best. Plus eight HDMI inputs — including one in front for easy access — let you connect all your high-def equipment. And let's not forget that there are two HDMI outputs to connect to your TV and projector. But movies, video games and TV are just the beginning.

Just plug your iPod® USB port to get the beat started. This direct digital connection delivers a pure digital signal to the 'NR616's superior processor so your music sounds awesome. Use the Ethernet port to connect the 'NR616 to your broadband home network, or if you have a wireless network, you can use Onkyo's optional Wi-Fi® adapter. Either way, you'll get easy access to the music files stored on your networked computers. Then dive in to thousands of Internet radio stations — so you can enjoy entertainment from every corner of the Earth. Your potential playlist just went exponential. Add to that the ability to stream music from Internet streaming sources like Pandora® Internet radio, Spotify®, Sirius/XM® Internet radio, Rhapsody® and more (may require registration and subscription fees).

The 'NR616 comes equipped with Audyssey® sound-shaping tools, to automatically balance and equalize the sound based on your room's acoustics. Plus Dolby® volume maintains optimum dynamics, so gone are the commercial sponsor's surprise attacks of sound. Onkyo's InstaPrevue™ system lets you see thumbnails of digital video sources on-screen, taking out the guesswork of which source is plugged into what port. You also get a graphic user interface to make control easy and intuitive with overlays on your TV screen. And you can download a free app to use your iPhone®, iPad® and Android™ devices as powerful Wi-Fi® system remotes.

Learn about the ins and outs of HDMI connections at the Crutchfield Learning Center.
Shop our selection of HDMI cables.

• 7-channel amplifier
• 100 watts per channel into 8 ohms (20-20,000 Hz) at 0.08% THD, with 2 channels driven
• THX® Select2 Plus™ certification guarantees pristine home theater sound
• Dolby® TrueHD, DTS-HD™ Master Audio, Dolby® Digital Plus, DTS-HD™ High Resolution Audio and Dolby Pro Logic® IIz
• Audyssey DSX® processing for enhanced surround sound height or width effects using additional front speakers
• analog-to-HDMI video upconversion (up to 1080p) with Marvell Qdeo™ video processing
• Audyssey 2EQ® auto speaker calibration (microphone included)
• Audyssey Dynamic Volume™ mode to maintain steady listening levels
• Audyssey Dynamic EQ™ for fuller surround sound at lower volumes

• direct digital connection of iPod®/iPhone® through front-panel USB input allows music control via receiver's remote
• DLNA (Digital Living Network Alliance) certified to ensure optimal compatibility with other network-enabled equipment
• Wi-Fi ready, requires separate adapter
• Internet streaming capabilities for Internet radio, Spotify®, SIRIUS/XM® Internet radio, Pandora® Internet radio, Rhapsody® and more (may require registration and subscription fees)
• Bluetooth integration (requires optional optional Onkyo adapter)

• three-room/three-source output:
  • powered and line-level stereo audio output for 2nd room (using powered 2nd room stereo output allows 5.1 home theater in main room)
  • line-level stereo audio output for 3rd room

• high-current amplifier design
• 192kHz/24-bit Burr-Brown digital-to-analog converters for all channels
• direct mode switches off unnecessary circuitry to provide cleaner sound
• back surround speaker channels re-assignable for bi-amping compatible front left and right speakers
• Music Optimizer function enhances the sound quality of compressed music files

• 1080p-compatible HDMI switching: 8 in (including 1 front-panel input), 2 out
• HDMI version 1.4 with support for 3D video, Audio Return Channel, Deep Color, x.v.Color, auto lip-sync, and HDMI-CEC
• Audio Return Channel function receives digital audio signals from a compatible HDTV's tuner via HDMI
• digital audio inputs: 2 optical and 2 coaxial
• 5 audio/video inputs, including:
  • 1 front-panel input with composite video
  • 4 rear-panel inputs with composite and component video
• no phono input — to connect a turntable you'll need to add a phono preamp
• Ethernet port for music streaming from a PC network
• 2 audio outputs for powered subwoofers
• 1 pair of main speaker outputs

• overlaid on-screen display via HDMI for easier setup and operation
• 40 AM/FM presets
• multibrand remote
• Onkyo's free remote app lets you use your iPod touch®, iPhone® or Android™ device as a Wi-Fi remote
• 17-1/8"W x 6-13/16"H x 13-3/8"D
• Weight: 24.3 lbs.
• MFR # TX-NR616
